Part numbers
- TH320-A001-0002
Full specifications
| Resolution | 300 dpi |
|---|---|
| Print width | 2 inch |
| Printing method | Direct Thermal / Thermal Transfer |
| Print head type | Flat Head |
| Max printing speed | 203 mm/sec |
| Max printing width | 56.9 mm |
| Max printing length | 11430 mm |
| Label width | 15 - 60 mm |
| Label length | 5 - 11430 mm |
| Max labels roll diameter | 127 mm |
| Interfaces | USB 2.0, RS-232, USB Host, Internal Ethernet 10/100 Mbps |
| Memory | 128 MB Flash memory, 128 MB SDRAM, microSD card reader for Flash memory expansion (max. 512 GB, FAT32 and exFAT only) |
| Optional | MFi Bluetooth 5.0, Peel-off module, Guillotine cutter (full cut and partial cut), Care label cutter (full cut), 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 5.0 combo module, Bluetooth 5.0 module, External label roll mount, KP-200 Plus keyboard display unit |
| Dimensions | 146 x 179 x 231 mm |
Compatible consumables
Thermal Transfer Ribbons
GPX PREMIUM
- Coated on
- PET film - 12 μm
- Printing temperature
- 110-160 °C
View details →
Thermal Transfer Ribbons
KTR PREMIUM
- Coated on
- PET film - 23,5 μm
- Printing temperature
- 115-125 °C
View details →
Thermal Transfer Ribbons
M110A PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
Thermal Transfer Ribbons
M110T PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
